About this item

• [15 PORTS OF CONNECTIVITY]: 2x Thunderbolt 3 40Gb/s, DisplayPort 1.2, 5x USB-A & 1 USB-C 3.1 Gen 1 (5Gb/s), 1x USB-C 3.1 Gen2 (10Gb/s data only), Gigabit Ethernet, UHS-II SD Card Slot (SD 4.0), Optical Audio (S/PDIF), 3.5mm Stereo Audio In & Out. Vertical or horizontal orientation. Sturdy full aluminum construction with integrated heat sink without a fan.
• [IMPROVED from 85W to 87W LAPTOP CHARGING]: Provides up to 87W to charge your laptop and power all of your USB peripherals. The secondary Thunderbolt 3 port provides 15W of power for downstream devices. Please note: Firmware update for the 87W charging already applied.
• [DUAL 4K EXTENDED DISPLAYS]: Connect up to two 4K@60Hz (4096 x 2160 30-bit color) monitors via DisplayPort and Thunderbolt 3 / USB-C port, OR a Single 5K@60Hz display can be supported via the Thunderbolt 3 port. (***DisplayPort to HDMI/DVI/VGA adapter / cable must be an ACTIVE type. Passive dongle/cable would not work.***)
• [UHS-II SD 4.0 CARD SLOT]: Latest UHS-II SD card slot supports SD/SDHC/SDXC at up to 312 MB/s bus speed. Transfer full days of footage from your camera 3x faster than UHS-I counterpart!
• [MAC & WINDOWS COMPATIBLE]: Ideal for 2016+ MacBook Pro, 2017+ iMac Pro, on Mac OS 10.12 or Windows 8/10 with a Thunderbolt 3 port. (Not compatible with 2015+ MacBook-Retina with USB-C port. Please use CalDigit USB-C Dock with MacBook-Retina)

Technical Specifications

System Requirements

• Thunderbolt 3 Computer | MacOS 10.12 or later | Windows 8, 8.1, 10 or later

Dimensions and Weight

• Height: 5.15 inches (131.0 mm) | Width: 1.57 inches (40.0 mm) | Depth: 3.87 inches (98.44 mm) | Weight: 1.04 lbs (0.47 kgs)

Interface

• 2 x Thunderbolt 3
• 1 x DisplayPort 1.2
• 5 x USB 3.1 Type-A (Gen1-5Gbps/5V 1.5A) | 2 x USB 3.1 Type-C (5V 1.5A)(1 x Gen1-5Gbps) (1 x Gen2-10Gbps)
• 1 x SD Card Reader (SD 4.0 UHS-II)
• 1 x Digital Optical Audio (S/PDIF)
• 1 x Gigabit Ethernet
• 1 x Analog Audio In (Stereo) | 1 x Analog Audio Out (Stereo)

Max. Video Resolution

• Thunderbolt 3: 5120 x 2880 60Hz | DisplayPort : 4096 x 2160 60Hz
